AN INDISPENSABLE OVER-POWER
Installed on all types of vehicles from 10 to 26 tons Total Weight, all models of SHM II DALBY are equipped with a super powerful hydraulic system thus offering "extra power" in order to face the most tricky situations.

. Detachment and pick-up of overloaded caisson on oily grounds provoking a suction effect, or on steep grounds.
. Transfer on caissons’ trailers of 16 tons keeping away from the drawhook thus avoiding crushing
. Complete tipping of most heavy caissons with angles at 47° to 53° according to the SHM II models.
. Elevation of the feet of the fertilizer caissons to allow the passage of spreaders or seedlers up to 2,50 m high.

AFNOR NORMS AND ADAPTABILITY
Thanks to its lateral keying system, its bracket height and its loading way, the SHM II answers to the NF R.17.107 norms. This way it can retake and handle all types of caissons conform with these norms or assimilated.
It demonstrates of a will from DALBY containers to adapt to park-caissons already existing with their new customers.

DEAD WEIGHTS AND MINIMUM BULKINESS
The flexible high quality iron structure of the SHM II offers the best ratio weight/robustness allowing thus a maximum effective load.
Moreover through its small bulkiness the SMH II ensures good visibility in the back from the commands station easing, thus, all handlings.

COMFORT OF USE AND SECURITY
The driver has at hand a pneumatic command station which allows to control smooth and precise movements.
Beyond its ease of use the SHM II is equipped with a set of elements providing maximum security:

The 3-points keying ensures:

• the complete locking of the caisson and the rigidity of the arm during the tipping and the tranportation phases
• the complete unlocking during the retaking and transboarding phases

Control lamp "closed hooks" allow the immediate checking of the locking at the level of the command desk.
Anti-fall valves block the jacks in case of rupture of the wire
Security of the hydraulic circuit preventing bad manoeuvers.

THOROUGHLY TESTED MATERIAL
Whether they are jacks conceived and developped in our workshops, from the smallest to the most powerful ones, or world famous piston pumps, all mechanical and hydraulic components composing the SHM II are submitted to rigorous testing of reliability and durability on an automated testing bench.
